400T Deck Barge

Length: 35m

Width: 9.0m

Depth: 2.5m

Rib distance: 50cm

Side plate thickness: 8mm

Bottom plate thickness: 10mm

Deck thickness: 12mm

Plate material: CCSA Marine board

Item 400T Flat Deck Steel-structured Barge Note
Model YS-400
Dimensions and materials Length 35m
Width 9.0m
Depth 2.5m
Rib distance 50cm
Side plate thickness 8mm Spraying 4 layers of special marine epoxy zinc-rich paint
Bottom plate thickness 10mm
Deck thickness 12mm
Plate material CCSA Marine board
Performance Non load draught 0.8m
Full load draught 2.0m
Load 400T
Deck load 7t/㎡
Total weight About 150T
